Panasonic CS-XU24BKH-1 / CU-XU24BKH 2.5HP X-Premium Inverter R32 Wi-Fi Air Conditioner Set
Complete matched set: indoor unit CS-XU24BKH-1 and outdoor unit CU-XU24BKH. Product only. Professional installation, piping, wiring, brackets and site works are quoted separately.
nanoe X Generator Mark3, nanoe-G, Clean Air Indicator, Inside Cleaning On Demand, ECO Mode with A.I. Control, AEROWINGS and humidity-sensor control with Dry Mode and iAUTO-X. Built-in Wi-Fi supports Panasonic Comfort Cloud app control. App features require compatible Wi-Fi and the app.
Specifications
Indoor model
CS-XU24BKH-1
Outdoor model
CU-XU24BKH
Horsepower
2.5 HP
Cooling capacity kW (min-max)
6.60 (1.50-7.18)
Cooling capacity Btu/h (min-max)
22,500 (5,120-24,500)
EER Btu/hW (min-max)
12.23 (20.48-11.95)
EER W/W (min-max)
3.59 (6.00-3.50)
CSPF W/W
6.13
Voltage V
220-240
Current A (220-240 V)
8.5-7.9
Power input W (min-max)
1,840 (250-2,050)
Moisture removal L/h
3.7
Air circulation indoor m3/min (ft3/min)
19.9 (700)
Air circulation outdoor m3/min (ft3/min)
34.9 (1,230)
Indoor noise H/L/Q-Lo dB(A)
45/34/28
Outdoor noise H dB(A)
52
Indoor dimensions H x W x D mm
295 x 1,060 x 249
Outdoor dimensions H x W x D mm
619 x 824 x 299
Net weight indoor kg
12
Net weight outdoor kg
32
Liquid pipe mm
6.35
Gas pipe mm
12.70
Chargeless pipe length m
10.0
Maximum pipe length m
30
Maximum elevation m
20
Additional refrigerant g/m
15
Power supply connection
Indoor
Airflow feature
AEROWINGS
Wireless remote
Standard
Wired controller
CZ-RD514C optional
Wi-Fi
Built in; Comfort Cloud app
Refrigerant
R32
Type
Inverter
nanoe X
Generator Mark3
nanoe-G
Included
Clean Air Indicator
Included
Humidity sensor
Included; Dry Mode and iAUTO-X
Specifications follow Panasonic Malaysia’s official 2025 XU BKH brochure, linked from the exact-model product page. Refer to the installation instructions before installation.
Warranty
Panasonic Malaysia warranty terms and purchase eligibility apply. Retain your invoice and confirm registration and coverage terms with Panasonic Malaysia.
